Manage MariaDB credentials using KubeVault operator

mariadb credentials using kubevault operator

With the use of HashiCorp Vault’s dynamic secrets engine, the KubeVault Operator makes managing MariaDB credentials in Kubernetes much safer and more effective. KubeVault makes it possible to automatically generate, rotate, and revoke database credentials on demand, doing away with the need for static secrets or hardcoded passwords. This significantly lowers the possibility of credential sprawl, abuse, and secret leaks by guaranteeing that apps always utilize temporary, least-privilege credentials.

KubeVault provides fully automated credential lifecycle management and policy-driven access control without the need for human involvement by integrating Vault directly into Kubernetes. MariaDB credentials can be requested by applications as regular Kubernetes Secrets, and Vault will automatically revoke them when they are no longer required and continuously rotate them based on set TTLs. This method improves compliance and auditability for production workloads while fortifying security. Manage MariaDB credentials using KubeVault Operator by safely automating the creation, rotation, and revocation of database secrets in Kubernetes using Vault’s dynamic secrets engine.

Organizations can maintain application workflows while standardizing secret management across teams and clusters with KubeVault. In the background, Vault ensures that the Kubernetes Secrets credentials developers use are always up to date, secure, and compliant. KubeVault is the perfect option for contemporary, cloud-native MariaDB deployments because of its automation, security, and ease of use.

Why Use KubeVault for MariaDB Secrets Management

By incorporating HashiCorp Vault’s features into Kubernetes, KubeVault offers a contemporary, automated method of maintaining MariaDB credentials. Instead of using regular Kubernetes Secrets, which are static secrets, KubeVault provides credentials that are dynamically produced and have a brief lifespan. Vault rotates these credentials automatically. Because passwords expire rapidly and don’t need to be handled manually, this reduces the possibility of credential leaks or misuse and removes the dangers associated with embedding passwords in configuration files or container images.

Manage MariaDB credentials using KubeVault operator is made secure and hands-off. Applications can use credentials without alteration because they are kept as standard Kubernetes Secrets, cycle automatically, and are supplied on demand. In order to minimize human error and eliminate the need for manual interventions during credential upgrades, vault policies specify granular, least-privilege access for developers, CI/CD pipelines, and services without resulting in downtime.

For production-grade MariaDB settings, KubeVault improves compliance and audit preparedness in addition to security and automation. By keeping a thorough audit history of each secret request, rotation, and revocation, Vault helps businesses comply with legal requirements while upholding strict security procedures. KubeVault enhances operational effectiveness, fortifies security posture, and frees up teams to concentrate on feature delivery rather than handling sensitive data by simplifying credential management.

Deploy Vault on Kubernetes

Pre-requisites

By offering a safe and feature-rich method of managing private data, including database credentials, API keys, and passwords, HashiCorp Vault gets beyond the drawbacks of Kubernetes’ native Secrets. Unlike standard Kubernetes Secrets, Vault provides enterprise-grade security through encryption, fine-grained access control, dynamic credential generation, and automated rotation. In order to assist with compliance, it also provides comprehensive audit logs, a variety of authentication options, and smooth Kubernetes integration.

You need to configure your environment to manage MariaDB credentials using KubeVault operator before you can deploy Vault on Kubernetes.

Prerequisites:

Familiarity with Vault and Kubernetes concepts such as clusters, pods, services, and secrets.
A running Kubernetes cluster (this guide uses Kind)).
Helm installed on your system.

Once these conditions are satisfied, HashiCorp Vault can be deployed in Kubernetes using KubeVault. Before you begin, make sure KubeVault is already set up in your cluster. You can obtain a free license from the AppsCode License Server by providing your cluster ID. To obtain the cluster ID, use the command below:

$ kubectl get ns kube-system -o jsonpath='{.metadata.uid}'
e5b4a1a0-5a67-4657-b370-db7200108cae

After providing the necessary information and hitting the submit button, the license server will email a “license.txt” file. To install KubeVault, run the following commands:

$ helm install kubevault oci://ghcr.io/appscode-charts/kubevault \
  --version v2025.2.10 \
  --namespace kubevault --create-namespace \
  --set-file global.license=/path/to/the/license.txt \
  --wait --burst-limit=10000 --debug

Verify the installation by the following command:

$ kubectl get pods --all-namespaces -l "app.kubernetes.io/instance=kubevault"
NAMESPACE   NAME                                                  READY   STATUS    RESTARTS   AGE
kubevault   kubevault-kubevault-operator-f89555d55-rwf49          1/1     Running   0          64m
kubevault   kubevault-kubevault-webhook-server-6497bb6d69-4wvpr   1/1     Running   0          64m

Within a short time all the pods in kubevault namespace will start running. If all pod statuses are running, we can move on to the next phase.

For any confusion regarding KubeVault installation, you can follow the KubeVault-Setup page.

Create a Namespace

After that, we’ll create a new namespace in which we will deploy Vault Server. In this case, we have created vault-demo namespace, but you can create namespace with any name that you want. To create the namespace, we can use the following command:

$ kubectl create namespace demo
namespace/demo created

Deploy VaultServer via Kubernetes KubeVault operator

We need to create a yaml configuration to deploy HashiCorp Vault Server on Kubernetes. We will apply the following yaml:

apiVersion: kubevault.com/v1alpha2
kind: VaultServer
metadata:
  name: vault
  namespace: demo
spec:
  allowedSecretEngines:
    namespaces:
      from: All
  version: 1.18.4
  replicas: 3
  backend:
    raft:
      storage:
        storageClassName: "standard"
        resources:
          requests:
            storage: 1Gi
  unsealer:
    secretShares: 5
    secretThreshold: 3
    mode:
      kubernetesSecret:
        secretName: vault-keys
  terminationPolicy: WipeOut

In this yaml,

spec.replicas specifies the number of Vault nodes to deploy. It has to be a positive number. Note: Amazon EKS does not support HA for Vault. As we using Amazon EKS as our backend it has to be 1.
spec.version specifies the name of the VaultServerVersion CRD. This CRD holds the image name and version of the Vault, Unsealer, and Exporter.
spec.allowedSecretEngines defines the Secret Engine informations which to be granted in this Vault Server.
spec.backend is a required field that contains the Vault backend storage configuration.
spec.unsealer specifies Unsealer configuration. Unsealer handles automatic initializing and unsealing of Vault.
spec.terminationPolicy field is Wipeout means that vault will be deleted without restrictions. It can also be “Halt”, “Delete” and “DoNotTerminate”. Follow this guide to learn more about KubeVault’s termination policy.

We will save this yaml configuration to vault.yaml. Then create the above HashiCorp Vault Server object.

$ kubectl apply -f vault.yaml
vaultserver.kubevault.com/vault created

This will create a VaultServer custom resource. The KubeVault Kubernetes Operator will watch this and create three HashiCorp Vault Server pods in the specified namespace. If all the above steps are handled correctly and the Vault is deployed, you will see that the following objects are created:

$ kubectl get pod,vaultserver -n demo
NAME                     READY   STATUS    RESTARTS   AGE
pod/vault-0              2/2     Running   0          7m5s
pod/vault-1              2/2     Running   0          6m39s
pod/vault-2              2/2     Running   0          6m15s

NAME                              REPLICAS   VERSION   STATUS   AGE
vaultserver.kubevault.com/vault   3          1.18.4    Ready    7m29s

We have successfully deployed Vault in Kubernetes with the Kubernetes KubeVault operator. Now, we will connect to the deployed Vault Server and verify whether it is usable or not. First, check the status,

$ kubectl get vaultserver -n demo
NAME    REPLICAS   VERSION   STATUS   AGE
vault   3          1.12.1    Ready    5m48s

From the output above, we can see that the VaultServer is ready to use.

Install KubeDB on Kubernetes

To set up KubeDB in our Kubernetes cluster, we need a license. Through the Appscode License Server, we can get a free enterprise license. We must provide our Kubernetes cluster ID to obtain a license. Run the following command below to get the cluster ID.

$ kubectl get ns kube-system -o jsonpath='{.metadata.uid}'
e5b4a1a0-5a67-4657-b370-db7200108cae

The license server will email us with a “license.txt” file attached after we provide the necessary data. Run the following commands listed below to install KubeDB.

$ helm install kubedb oci://ghcr.io/appscode-charts/kubedb \
  --version v2025.4.30 \
  --namespace kubedb --create-namespace \
  --set-file global.license=/path/to/the/license.txt \
  --wait --burst-limit=10000 --debug

Verify the installation by the following command,

kubectl get pods --all-namespaces -l "app.kubernetes.io/instance=kubedb"
NAMESPACE   NAME                                           READY   STATUS    RESTARTS   AGE
kubedb      kubedb-kubedb-autoscaler-0                     1/1     Running   0          6m3s
kubedb      kubedb-kubedb-ops-manager-0                    1/1     Running   0          6m3s
kubedb      kubedb-kubedb-provisioner-0                    1/1     Running   0          6m3s
kubedb      kubedb-kubedb-webhook-server-fb76b7889-qf4ng   1/1     Running   0          6m3s
kubedb      kubedb-petset-5dbd674f4b-hnmwj                 1/1     Running   0          6m3s
kubedb      kubedb-sidekick-6756758dd6-zl5w5               1/1     Running   0          6m3s

Create a MariaDB database

We need to create a yaml manifest to install MariaDB on Kubernetes. And we will apply this yaml below,

apiVersion: kubedb.com/v1
kind: MariaDB
metadata:
  name: mariadb-quickstart
  namespace: demo
spec:
  deletionPolicy: Delete
  storage:
    accessModes:
    - ReadWriteOnce
    resources:
      requests:
        storage: 1Gi
    storageClassName: standard
  storageType: Durable
  version: 11.1.3

We will save this yaml configuration to mariadb.yaml. Then create the above MariaDB object.

$ kubectl apply -f mariadb.yaml
mariadb.kubedb.com/mariadb-quickstart created

If all the above steps are handled correctly and the MariaDB is deployed, you will see that the following objects are created:

$ kubectl get pod,mariadb -n demo
NAME                        READY   STATUS    RESTARTS   AGE
pod/mariadb-quickstart-0      1/1     Running   0          2m59s


NAME                                    VERSION   STATUS   AGE
mariadb.kubedb.com/mariadb-quickstart       6.2.14    Ready    3m2s

Manage MariaDB credentials using KubeVault

Enable and Configure MariaDB Secret Engine

When a SecretEngine crd object is created, the KubeVault operator will enable a secret engine on specified path and configure the secret engine with given configurations.

A sample SecretEngine object for the MariaDB secret engine:

apiVersion: engine.kubevault.com/v1alpha1
kind: SecretEngine
metadata:
  name: mariadb-secret-engine
  namespace: demo
spec:
  vaultRef:
    name: vault
    namespace: demo
  mariadb:
    databaseRef:
      name: mariadb-quickstart
      namespace: demo
    pluginName: "mysql-database-plugin"

Let’s deploy SecretEngine:

$ kubectl apply -f mariadb-secretengine.yaml
secretengine.engine.kubevault.com/mariadb-secret-engine created

Wait till the status become Success:

$ kubectl get secretengine -n demo
NAME                      STATUS    AGE
mariadb-secret-engine     Success   10s

Since the status is Success, the MariaDB secret engine is enabled and successfully configured. You can use kubectl describe secretengine -n <namepsace> <name> to check for error events, if any.

Create MariaDB Role

By using MariaDBRole, you can create a role on the Vault server in Kubernetes native way.

A sample MariaDBRole object is given below:

apiVersion: engine.kubevault.com/v1alpha1
kind: MariaDBRole
metadata:
  name: mariadb-role
  namespace: demo
spec:
  secretEngineRef:
    name: mariadb-secret-engine
  creationStatements:
    - "CREATE USER '{{name}}'@'%' IDENTIFIED BY '{{password}}';"
    - "GRANT SELECT ON *.* TO '{{name}}'@'%';"
  defaultTTL: 1h
  maxTTL: 24h

Let’s deploy MariaDBRole:

$ kubectl apply -f mariadbrole.yaml
mariadbrole.engine.kubevault.com/mariadb-role created

$ kubectl get mariadbrole -n demo
NAME           STATUS    AGE
mariadb-role     Success   34m

You can also check from Vault that the role is created. To resolve the naming conflict, name of the role in Vault will follow this format: k8s.{clusterName}.{metadata.namespace}.{metadata.name}.

Don’t have Vault CLI? Download and configure it as described.

$ vault secrets list
Path                 Type         Accessor              Description
you-database-path    database     database_cac6c5ee     n/a


$ vault list your-database-path/roles
Keys
----
k8s.-.demo.mariadb-role

$ vault read your-database-path/roles/k8s.-.demo.mariadb-role
Key                      Value
---                      -----
creation_statements      [CREATE USER '{{name}}'@'%' IDENTIFIED BY '{{password}}'; GRANT SELECT ON *.* TO '{{name}}'@'%';]
credential_type          password
db_name                  k8s.9b6fcff6-f32b-4072-81e1-a70d32f1a12f.demo.mariadb-quickstart
default_ttl              1h
max_ttl                  24h
renew_statements         []
revocation_statements    []
rollback_statements      []

If we delete the MariaDB, then the respective role will be deleted from the Vault.

$ kubectl delete mariadbrole -n demo mariadb-role
mariadbrole.engine.kubevault.com "mariadb-role" deleted

Check from Vault whether the role exists:

$ vault read your-database-path/roles/k8s.-.demo.mariadb-role
No value found at your-database-path/roles/k8s.-.demo.mariadb-role

$ vault list your-database-path/roles
No value found at your-database-path/roles/

Generate MariaDB credentials

Here, we are going to make a request to Vault for MariaDB credentials by creating mariadb-access-req SecretAccessRequest in demo namespace.

apiVersion: engine.kubevault.com/v1alpha1
kind: SecretAccessRequest
metadata:
  name: mariadb-access-req
  namespace: demo
spec:
  roleRef:
    kind: MariaDBRole
    name: mariadb-role
    namespace: demo
  subjects:
    - kind: ServiceAccount
      name: demo-sa
      namespace: demo

Here, spec.roleRef is the reference of MariaDB against which credentials will be issued. spec.subjects is the reference to the object or user identities a role binding applies to it will have read access of the credential secret.

Now, we are going to create SecretAccessRequest.

$ kubectl apply -f mariadbSecretAccessRequest.yaml
secretaccessrequest.engine.kubevault.com/mariadb-access-req created

$ kubectl get secretaccessrequest -n demo
NAME                 AGE
mariadb-access-req     72m

Database credentials will not be issued until it is approved. The KubeVault operator will watch for the approval in the status.conditions[].type field of the request object. You can use KubeVault CLI, a kubectl plugin, to approve or deny SecretAccessRequest.

# using KubeVault CLI as kubectl plugin to approve request
$ kubectl vault approve secretaccessrequest mariadb-access-req -n demo
secretaccessrequests mariadb-access-req approved


$ kubectl get secretaccessrequest -n demo mariadb-access-req -o yaml
apiVersion: engine.kubevault.com/v1alpha1
kind: SecretAccessRequest
metadata:
  annotations:
    kubectl.kubernetes.io/last-applied-configuration: |
      {"apiVersion":"engine.kubevault.com/v1alpha1","kind":"SecretAccessRequest","metadata":{"annotations":{},"name":"mariadb-access-req","namespace":"demo"},"spec":{"roleRef":{"kind":"MariaDBRole","name":"mariadb-role","namespace":"demo"},"subjects":[{"kind":"ServiceAccount","name":"demo-sa","namespace":"demo"}]}}
    vaultservers.kubevault.com/name: vault
    vaultservers.kubevault.com/namespace: demo
  creationTimestamp: "2025-08-08T07:02:45Z"
  finalizers:
  - kubevault.com
  generation: 1
  name: mariadb-access-req
  namespace: demo
  resourceVersion: "95423"
  uid: 4d00e64f-bda5-4b33-8312-e3680be86bab
spec:
  roleRef:
    kind: MariaDBRole
    name: mariadb-role
    namespace: demo
  subjects:
  - kind: ServiceAccount
    name: demo-sa
    namespace: demo
status:
  conditions:
  - lastTransitionTime: "2025-08-08T07:03:33Z"
    message: 'This was approved by: kubectl vault approve secretaccessrequest'
    observedGeneration: 1
    reason: KubectlApprove
    status: "True"
    type: Approved
  - lastTransitionTime: "2025-08-08T07:03:33Z"
    message: The requested credentials successfully issued.
    observedGeneration: 1
    reason: SuccessfullyIssuedCredential
    status: "True"
    type: Available
  lease:
    duration: 1h0m0s
    id: k8s.9b6fcff6-f32b-4072-81e1-a70d32f1a12f.mariadb.demo.mariadb-secret-engine/creds/k8s.9b6fcff6-f32b-4072-81e1-a70d32f1a12f.demo.mariadb-role/5VCEcJkQLK3KtKZ86KePZaFZ
    renewable: true
  observedGeneration: 1
  phase: Approved
  secret:
    name: mariadb-access-req-feuq0s
    namespace: demo

Once SecretAccessRequest is approved, the KubeVault operator will issue credentials from Vault and create a secret containing the credential. It will also create a role and rolebinding so that spec.subjects can access secret. You can view the information in the status field.

$ kubectl get secretaccessrequest mariadb-access-req -n demo -o json | jq '.status'
{
  "conditions": [
    {
      "lastTransitionTime": "2025-08-08T07:03:33Z",
      "message": "This was approved by: kubectl vault approve secretaccessrequest",
      "observedGeneration": 1,
      "reason": "KubectlApprove",
      "status": "True",
      "type": "Approved"
    },
    {
      "lastTransitionTime": "2025-08-08T07:03:33Z",
      "message": "The requested credentials successfully issued.",
      "observedGeneration": 1,
      "reason": "SuccessfullyIssuedCredential",
      "status": "True",
      "type": "Available"
    }
  ],
  "lease": {
    "duration": "1h0m0s",
    "id": "k8s.9b6fcff6-f32b-4072-81e1-a70d32f1a12f.mariadb.demo.mariadb-secret-engine/creds/k8s.9b6fcff6-f32b-4072-81e1-a70d32f1a12f.demo.mariadb-role/5VCEcJkQLK3KtKZ86KePZaFZ",
    "renewable": true
  },
  "observedGeneration": 1,
  "phase": "Approved",
  "secret": {
    "name": "mariadb-access-req-feuq0s",
    "namespace": "demo"
  }
}

$ kubectl get secret -n demo mariadb-access-req-feuq0s -o yaml
apiVersion: v1
data:
  password: VFotbUN3S1JnaVRyUnhIRHQzblc=
  username: di1rdWJlcm5ldGVzLWs4cy45YjZmY2YtOFk0U2RLNlg=
kind: Secret
metadata:
  creationTimestamp: "2025-08-08T07:03:33Z"
  name: mariadb-access-req-feuq0s
  namespace: demo
  ownerReferences:
  - apiVersion: engine.kubevault.com/v1alpha1
    blockOwnerDeletion: true
    controller: true
    kind: SecretAccessRequest
    name: mariadb-access-req
    uid: 4d00e64f-bda5-4b33-8312-e3680be86bab
  resourceVersion: "95419"
  uid: 807ea614-ae4d-4a74-9614-87bd9033bd74
type: Opaque

If SecretAccessRequest is deleted, then credential lease (if any) will be revoked.

$ kubectl delete secretaccessrequest -n demo mariadb-access-req-feuq0s
secretaccessrequest.engine.kubevault.com "mariadb-access-req-feuq0s" deleted

If SecretAccessRequest is Denied, then the KubeVault operator will not issue any credential.

$ kubectl vault deny secretaccessrequest mariadb-access-req-feuq0s -n demo
  Denied

Conclusion

Manage MariaDB credentials using KubeVault operator , teams can handle database secrets centrally, automatically, and securely. This reduces risk and complies with modern compliance and DevOps practices. Through audits, encryption, authentication, and authorization, MariaDB’s built-in security capabilities already offer a solid enterprise-grade foundation when set up correctly. This foundation is strengthened by integrating KubeVault, which significantly reduces the dangers associated with static secrets through dynamic secrets management, automated credential rotation, and policy-driven access control.

To ensure automated, compliant, and risk-free database access in Kubernetes, manage MariaDB credentials using KubeVault operator, which combines Vault’s dynamic secrets with MariaDB’s built-in security capabilities.

From simple authentication to more complex features like field-level encryption and safe network isolation, this tutorial has demonstrated how HashiCorp Vault’s secrets engine functions in tandem with MariaDB’s security features. KubeVault extends Vault’s functionality directly into Kubernetes to offer centralized and automated credential lifecycle management. Combining MariaDB’s TLS/SSL and access restrictions with Vault’s RBAC and automated rotation creates a robust, defense-in-depth security strategy that meets modern compliance needs.

Administrators may preserve performance and dependability while handling secrets uniformly across environments by integrating KubeVault into MariaDB operations. This method ensures the highest level of protection for sensitive data while providing the agility needed for today’s cloud-native apps.

KubeDB

KubeStash New

Stash

KubeVault

Voyager

ConfigSyncer

Guard

RESOURCES

Vault Kubernetes Deployment

Auto Initialization & Unsealing

Vault Backup & Restore

Consume KubeVault Secrets with CSI

Manage DB Users Privileges

Storage Backend

Authentication Method

Database Secret Engine

Azure Secret Engine

AWS Secret Engine

GCP Secret Engine

Kubectl Plugin
